Raaw Jibb V1 Fox Factory Kit - Contact us to order in

A limited batch of Fox Factory forks with the Grip2 Damper have arrived at our HQ and are ready for action! The Jibb V1 Fox Factory Kit is a dream chassis to start your individual build with a Float X, Float X2 or DHX2 of your choice and an Acros headset as standard.

The Jibb is made to ride up, down and chase its tail all over the mountains. It brings the Madonna’s DNA to an all-around more playful package and entices you to be an active part of the ride. The Jibb does demand more involvement from the rider when things get rough but doesn’t shy away from the big stuff one bit. The chassis gives you all the feedback and confidence you need and makes it an ideal companion for long rides in the hills all the way through to wild bike park days.

If you want to learn more about the Jibb, you can find all details on this page.

Protective Film is included in the price or ride wrap options are avaliable

DHX2 shock option includes SLS Spring of choice

(all dimensions in mm except for angles)

Travel rear/ front 135/ 150 (+10)
Wheel size 29” (740-755mm)
Max tire width 2.6” (66mm)
Tire clearance 84mm
Rear hub 148 x 12
Shifting One-by only, boost, 36t max
BB 73mm BSA / ISCG05
Brake 203mm Postmount
Seat tube diameter 31.6mm inside, 35mm outside
Internal seatpost routing Yes
Seatpost max insert S 205mm / M 230mm / L 255mm / XL 280mm
Headset 44 / 56 Zero stack
Cable routing All external
Tire to seat tube clearance 10 – 18mm (depending on size and tire)
Shock hardware Ball bearings and hardware included
Bearings main pivot 2 x 61808-2RS1 (52 x 40 x 7)
Bearings other pivots 10 x 91903-2RS1 (28 x 15 x 7)
Recommended fork dimensions ATC 560mm – Rake 44mm
Shock dimensions 185 x 55 – Trunnion
Weight 3.9 kg (incl. shock hardware, rear wheel axle and frame protection, w/o shock, size S)
Material AL 6066 T6
Finish options Matt Black and Raw with matt clear coat

• 1x Frame RAAW Jibb - Finish Raw or Black
• 1x RAAW rear wheel axle
• 1x Seatpost clamp RAAW
• 1x Protective film for the Jibb (if selected)
• 1x Chainstay Protector
• 1x Seatstay Protector
• 1x Down Tube Protector
• 1x Brake mount 203 mm
• Full Hardware for shock assembly
• 11 Zip ties
• Owners book

Fox Factory Kit Components:

• 1x 2023 Fox 36 Factory, 29” Boost wheel, 150 mm travel, Grip2 damper, 44 mm offset, 15QR axle, matte black with orange/matte black logo
• 1x Headset Acros

Optional shock choice:

• 1x Fox Float X Factory 2pos lever
• 1x Fox Float X2 Factory 2pos lever
• 1x Fox DHX2 Factory 2pos lever incl. Fox SLS spring
